FLANGE AND CONNECTORS FLANGEs and CONNECTORS 9

WIDE RANGE
CONNECTORS

MOD. 9320 PN 16 DN 40-600

Wide range connector.

MOD. 9330 PN 16 DN 40-300

Wide range connector, restraint type.

special features

• Universal connector with large range (up to 54 mm)
for CI, DI, steel, AC, PVC and PEAD pipes.

• Body and compression ring high quality EPOXY
powder coated (fusion bonded), coating thickness
(DFT min. 250 microns).

• Special tightening system with one bolt resp. two
bolts for DN≥300 dimensions.

• Internal compression ring and bolt/nut/washer from
fully corrosion-free material.

• Dual-gasket pressure assisted hydraulic sealing
system.

• The gasket is made in two layers, with a removable
inner layer that allows for pipe diameter range
expansion.

• Easily to be handled by one person even up to big
diameters.

• Model 9320 non-restraint type, it is suggested the
anchoring of pipeline.

• Ask to raci for ranges and availability of model 9330
(restraint).

All metal, rubber, and coatings used have been designed for contact with water for human consumption, pursuant to the terms of Italian Health Ministry decree
n° 174, dated 6/4/2004.
