FlaNge aND CONNeCtORs flanges and cOnnectOrs 9
universal flange
raci-range
MOd. 9200 pn 16 dn 50-600
Universal flange adaptor.
special features
• Universal flange adaptor with medium range for metal,
aC and PvC pipes, non-restraint.
• Body and compression ring high quality ePOXY
powder coated (fusion bonded), coating thickness
(DFt min. 250 microns), zero porosity (tested with
3000v), high impact resistance and cross-linkage
according to DIN 30677-2 and DIN 3476.
• Hydraulic sealing obtained by compression of gasket
between pipe and special seat on body.
• Bolts/nuts/washers from steel, high quality corrosion
protected.
• Universal flange drilling according to eN 1092-2 PN 10
and PN 16.
• the product is not restraint, anchoring of the pipe is
suggested.
All metal, rubber, and coatings used have been designed for contact with water for human consumption, pursuant to the terms of Italian Health Ministry decree
n° 174, dated 6/4/2004.
