PIPe saDDles pipe saddles 8
fiXing straps fOr
universal saddles
MOd. 8012 dn 80-400
Stainless steel strap and rubber cover.
MOd. 8100 dn 40-65
Stainless steel strap and rubber cover “Hynge type”.
L1
L2 L2
L1 L
Materials pawls:
strap: Reinforced Nylon
stainless steel 1.4301/ eN IsO10088 screws:
(correspondent to aIsI304) stainless steel 1.4301/ eN IsO10088
rubber cover: (correspondent to aIsI304)
NBR rubber
ties: Hynges:
stainless steel 1.4301/ eN IsO10088 stainless steel 1.4301/ eN IsO10088
(correspondent to aIsI304) (correspondent to aIsI304)
nuts and washers:
stainless steel 1.4301/ eN IsO10088
(correspondent to aIsI304)
DN Ø min - Ø max L L1 L2 Thickness
140 100 1,2
50 55-75 - 160 100 1,2
235 110 1,2
65 70-90 - 273 110 1,2
355 110 1,2
80 87-107 455 435 110 1,2
475 110 1,5
100 105-125 493 545 110 1,5
590 110 1,5
125 130-155 575 675 110 1,5
745 110 1,5
150 161-186 655 836 110 1,5
905 110 1,5
175 185-210 695 975 110 1,5
1060 110 1,5
200 215-240 765 1130 110 1,5
1262 110 1,5
200 230-255 810
250 260-285 895
250 285-310 965
300 315-340 1056
300 338-365 1125
350 368-394 1195
400 394-420 1280
400 418-443 1350
400 474-493 1482
All metal, rubber, and coatings used have been designed for contact with water for human consumption, pursuant to the terms of Italian Health Ministry decree
n° 174, dated 6/4/2004.
