aCCessORIes FOR sPaCeRs accessOries 13

tOOl fOr spacers

MOd. 13204 (a75) H. MaX 18-75 mm
H. MaX 90-200 mm
MOd. 13205 (a200)
fOr cOllar faMilies M / N / p / Q / L

MOd. 13206 (B75) H. MaX 25-75 mm
H. MaX 90-130 mm
MOd. 13207 (B130)
fOr cOllar faMilies e / h

MOd. 13208 (c90) H. MaX 18-90 mm
fOr cOllar faMilies M / N / F / G

Combined gear and threaded rod spacers clamp tool.

cHaracteristics You can apply the lever in
right-handed or left-handed mode.
• Movable and fixed stainless steel jaw with high
strength. The direction in which
it moves the “carriage”
• threaded chrome rod with special nitrating treatment when the lever moves
to increase the mechanical strength. downwards.

• Operating by standard reversible ratchet key tool POLYPROPYLENE CASE: 482 x 375 x132 mm
provided by safety lock device.
MOD. TOOL TOTAL WEIGHT (kg)
• simple and basic design with few elements.
13204 5,6
• Protection cap upon rotating gear to assure 13205 6,3
hand safety. 13206 6,1
13207 6,6
• Reduced clamping torque thanks to the big 13208 5,4
dimensions of the gear.

• New concept in handling: completely universal both
referring hand hold and tightening direction.

>> for assembling collars, strictly adhere to the
“asseMBly instructiOns” on page13.5
or the multilingual instructions manual which
comes as part of the supply.

Materials

Main body (fixed and mobile jaw):
stainless steel X5CRNICUNB16-4 - aIsI 630

Wheel pin:
Hardened steel gear

gear:
Hardened steel 38 n d4

self-lubricating bushing:
synthesized steel

protective cap:
Polycarbonate

M12 buffer and nut:
stainless steel a2

threaded rod:
galvanized hardened steel 40CRMNMO7 - aIsI P20
