REPAIR CLAMPS 10 repair clamps
H
repamax 12, 22 and 32
L1
lo
L
model 10601 - l = 140 mm
DNREPAMAX 12 TOT. RANGE SUP. H (mm) L1 (mm) PMA (bar)
REPAMAX 22 mm pollici 45-57 INF. - 125 160 24 16 12 11
52-64 - 135 160
50 1,5 59-71 - - 140 160 ••
50 2 71-84 - - 155 160 ••
50 2 81-93 - - 165 160 ••
65 2,5 - ••
80 3 87-109 - - 200 180 ••
80 3 104-126 - 218 180 •
100 4 108-131 - - 220 180 ••
100 4 113-136 - - 230 180 ••
100 4 121-144 - - 235 180 •
100 4 124-146 - - 239 180 ••
100 4 138-160 - - 260 180
125 5 147-169 - - 270 180 •
125 5 152-174 - - 268 180 ••
150 6 164-186 - - 275 180 ••
150 6 180-202 - - 293 180
150 6 190-212 - - 305 180 •
175 7 210-232 - - 323 210 •
200 8 244-267 - - 360 210 •
250 10 270-293 - - 390 210 •
250 10 286-308 - - 405 210 •
250 10 305-327 - - 420 210 •
300 12 322-344 - - 440 210 •
300 12 340-362 - - 460 210 •
350 14 - •
- •
Other ranges on demand. •
Io minimum values: up to OD 300: 45-60 mm
350≤OD≤600:60-75 mm
All metal, rubber, and coatings used have been designed for contact with water for human consumption, pursuant to the terms of Italian Health Ministry
decree n° 174, dated 6/4/2004.
