13 MOUNtINg

Hdpe spacers

special applicatiOns

anti-slip tape H DN QUANTITy SELF-AMALGAMATING TAPE
tape pipe C-D-I / S-T / A-B F-G M-N / P-Q / L / E-H
In case of plastic carrier pipe (PvC, Pe and similar)
or 3ply Pe coated steel pipe, it is suggested to apply m ft m ft m ft
the tape on the contact area between the ring and the
carrier pipe, in order to avoid any horizontal sliding of the 50 mm 2” 0,45 1,5 - - - -
rings on the carrier pipe during the inserting operations.
4” 0,75 2,5 1,65 5,4 - -
the table resumes the required quantity of tape for
each insulating ring referred to the different pipe size. 6” 1,2 4 2,4 7,9 3,45 11,4

HOW tO prOceed WitH tHe applicatiOn 8” 0,75 2,5 1,5 4,9 2,7 8,9

apply the tape on the surface of the pipe where the 10” 1,8 5,9 3,3 10,8
insulating ring will be placed. In case some more layers
are required to cover the entire width of the insulating 12” 2,1 6,9 4,05 13,3
ring, remove the protective film by wrapping it around
the pipe for an overlap of 50%. It is recommended to 16” 2,7 8,9 5,25 17,2
remove the protective film (interleaving) from the last
layer in contact with the insulating ring just before fixing 20” 3,3 10,8 6,6 21,8
the ring itself, so as to avoid a reduction in adhesion
(caused by deposit of dust, debris, rain, etc.). 100 mm 24” 7,8 25,7

Water Well applicatiOn 30” 9,75 32,2

RaCI spacers can be easily and reliably used as 32” 10,35 34,2
centralizers in water wells rising columns in order to avoid
the contact between the pipe and the casing and to have 36” 11,7 38,6
a better alignment of the submersible pump set.
40” 12,9 42,6
applicatiOn On cOrrugated pipes
42” 13,5 44,6
Using suitable technical devices, RaCI collars can also
be used on pipes with an external corrugated surface. 48” 15,45 51
after submitting the design and dimensional data to
RaCI’s technical department, the right solutions will be 52” 16,8 55,4
suggested to the installer.
56” 18 59,4

Belt applicatiOn

For crossings with multiple pipes for the conveyance of
different services (for example, fluids and conduits), it is
possible to use different series of rings: a series of rings
for spacing the flow pipe and another series arranged as
a belt to fix the additional services.

the experts of RaCI’s technical department can carry
out a detailed analysis of the application and propose
the best solution for the specific needs.

Ring of elements F41/G41 ø 1220

Corona di elementi F41/G41

ø 355.6 Belt consisting ø 35
of elements F25 ø 355

ø 355.6 ø 355.6

ø 355.6 Example of crossing with multiple pipes.

Example of belt consisting application. info@raci.it - www.raci.it - Tel. +39 02 262.351
