Accessories for Valves

Extension Spindles

• For underground installation, rigid
or telescopic types

• Operating spindle galvanised steel

• Spindle coupling and cap from ductile iron
galvanised

• Protecting tubes from plastic material incl.
suitable adaptor to fit exactly the shape
of the valve bonnet

• Telescopic type additionally sealed against
water and sand

• Various lengths (pipe cover depth)

Hand wheels / Operating caps / Base plates

surface boxes

• Telescopic type with adjustable rings,
from cast iron (ductile iron on demand)

• Fix type, body from polyethylene
and cover from ductile iron epoxy coated

air valves

• For potable water and sewage
• With single and double orifice
• With single, double and triple function
• Made from metal or from plastic material

Ductile iron

PN 10/16/25 DN 1” - 250

• Body and cover from ductile iron
to EN 1563, epoxy coated

• Float from plastic material or stainless steel

• Sealing seat from brass

PA + GF DN 1” - 2”
PN 10/16/25

• Body from PA + GF (composite)

• All internal parts from corrosion free materials
(PA, PP, silicone)

STAINLESS STEEL

PN 10 DN 2” - flange DN 50, 80 e 100

• For sewage
• All metal parts from stainless steel 304 (A2)
• Working device made from PA + GF (composite)
