water distribution

GATe VAlVes

RESIlIENt SEatED

• according to EN 1171 and
   EN 1074-1,2 (certified by ICIM)

• Body and bonnet from ductile iron
   to EN 1563, epoxy coated

• wedge from ductile iron to EN 1563,
   inside and outside fully rubber vulcanised

• Solid flexible wedge nut from
   non-corrosive material

• Multiple o-ring spindle sealing system
   to DIN 3547-1

• o-rings changeable under pressure
   to ISo 7259

• Non-rising stainless steel spindle (rolled)
   1.4021 (X20Cr13)

• From DN 250 and bigger complete
   with additional axial roller bearing

• Bolts protected by special resin

DouBlE FlaNgED,
SHoRt aND loNg BoDy

PN 10/16  DN 40 - 1000
PN 25     DN 40 - 300

RaCI-gRIP DouBlE SoCKEt
FoR PE/PVC PIPES, REStRaINt

PN 16     DN 50 - 300        De 63 - 315

DouBlE SoCKEt FoR PVC PIPES, NoN-REStRaINt

PN 16     DN 50 - 300        De 63 - 315

BotH SIDES INtEgRal PE taIlS FoR wElDINg

PN 10/16  DN 80 - 200        De 90 - 225

SPIgot tyPE to CoNNECt wItH
DuCtIlE IRoN PIPES SoCKEtS

PN 16     DN 50 - 300        De 65 - 338

Manual operation:
   Hand wheel / operating cap / Extension spindle

Automatic operation:
   Electric actuator (Standard: auMa)
