HDPE SPACERS 13 HDPE SPACERS

type f / g

TYPE USEFUL LENGTH WIDTH (B) HEIGHT (H) LOADING
capacity(kg)
mm inch mm inch mm inch

F 197 - 237 7,7 - 9,3 130 5,1 25- 41- 60 -75 0,98 - 1,61 500
2,36 - 2,95

G 91 - 129 3,6 - 5 25- 41-60 0,98-1,61-2,36

The loading capacity values are esteemed and verified under static and ideal conditions.

outside Ø main pipe d.e. spacer elements* (pcs.) RECOINMSMUELNADTOEDRSSP(AHCeINleGmBeEnTtW) EEN

ø MIN ø MAX Family Gas Water
F G **
92 115 11 mt feet mt feet
116 152 2-
153 188 21 2,5 8,2 2,5 8,2
189 224 3- 2,5 8,2 2,5 8,2
225 260 31 2,5 8,2 2,0 6,6
261 295 4- 2,5 8,2 2,0 6,6
296 313 41 2,0 6,6 2,0 6,6
314 376 5- 2,0 6,6 2,0 6,6
377 446 6- 2,0 6,6 2,0 6,6
477 528 7- 2,0 6,6 1,5 4,9
2,0 6,6 1,5 4,9
2,0 6,6 1,5 4,9

(*) number and type of elements to make one insulator ring around the entire circumference of the carrier pipe.

(**) The element G was designed as special pipe sizes for closing element in order to complete the circumferences on some pipe OD ranges.
Therefore it is not possible to use more than 1 elements G in a ring.

TYPE H (mm) Pieces for Carton Cartons weight (Kg)
F carton box dimensions (cm)
G 25 Net Gros
41 150 60 x 40 x 50
60 100 22 24
75 70 40 x 30 x 25 17 19
25 60 14 16
41 50 15 17
60 60
40 4,5 5,5
67
45

Note: for logistic reasons, deliveries are for full carton boxes only.
